NUC029LDE

The NuMicro^® NUC029LDE is a 32-bit microcontroller with embedded Arm^® Cortex^®-M0 core for industrial control and applications which need rich communication interfaces. NUC029LDE can run up to 50 MHz, has 68 KB flash, 4 KB LDROM and 8 KB SRAM. Many system level peripheral functions, such as PWM up to 12 channels, I/O port, Timer, 4 sets UART, SPI, PWM, ADC, Watchdog Timer, and Brown-out Detector.

Applications

• LED Control, Industrial Control, Motor Control, etc.

Key Features

• Operating Characteristics
  • Voltage range: 2.5 V ~ 5.5 V
  • Temperature range: -40°C ~ +105°C
• Core
  • Arm^® Cortex^®-M0 processor
  • Max frequency of 50 MHz
• Memories
  • 68 KB Flash for program memory
  • Provide 8 KB SRAM
  • 4 KB LDROM
  • Support ISP (In-System Programming)
  • Support ICP (In-Circuit Programming)
  • Support IAP (In-Application-Program)
• Clocks
  • 4 ~ 24 MHz external crystal oscillator
  • Internal 22.1184 MHz (1% accuracy at 25℃, 5V)
• PWM
  • Up to 12 channel PWM outputs or 3 complementary paired PWM outputs
  • Support Capture interrupt
• ADC
  • Up to 8 channels
  • 12-bit resolution
  • Up to 1 MSPS
• Connectivity
  • Up to 1 SPI (up to 36 MHz)
  • Up to 2 I²C (up to 400 kHz)
  • Up to 4 UART (up to 1 Mbps)
• Timer
  • 4 sets of 32-bit timers with 24-bit up-timer and one 8-bit prescale counter
• PDMA
  • Up to 9 channels
• Package
  • LQFP48 (7x7mm)
